Home  >  HVAC/R Components  >  Contactors  >  MARS 780 Contactors  > 2P 30A 120V LG BDY BL A2L

2P 30A 120V LG BDY BL A2L

Contactor Type Definite Purpose No. of Poles 2 FLA Inductive 30 FLA Resistive 40 Coil Voltage 120 A2L Compliance A2L Compliant Lug or Screw Terminal Box Lugs Standards UL Coil Hz. 50/60
Item #: 62426
2P 30A 120V LG BDY BL A2L
  • Designed for use on refrigeration, air conditioning and electric heating systems
  • Engineered for today's most demanding commercial refrigeration and HVAC applications
  • Enclosed body provides a quieter running contactor and a longer life expectanc
  • Oversized Arch Window to simplify wiring
  • High Performance Copper & Brass Conductors maximize current carrying capability creating a cooler running contactor
  • Multi-purpose Coil Terminals allow the use of QC terminals or stripped wires
  • Removable Coils allow field replacement of damaged coils
  • Removable Cover provides full access to the contacts
  • Thermoplastic Housing resists dusting and contamination of the contacts to maintain maximum conductivity
  • A2L Compliant design

    • Contactors

    Contactor Type
    Definite Purpose
    No. of Poles
    2
    FLA Inductive
    30
    FLA Resistive
    40
    Coil Voltage
    120
    A2L Compliance
    A2L Compliant
    Lug or Screw Terminal
    Box Lugs
    Standards
    UL
    Coil Hz.
    50/60
    Brand
    MARS
    Pack Qty
    1
    Case Qty
    30
    Length
    2.59 in.
    Width
    4.01 in.
    Height
    3.22 in.
    Weight
    1.1500 lbs
    Harmonized Tariff Code
    8536490065
    UPC
    685744624264
    Country of Origin Code
    CN
    Country of Origin Name
    China
